Protection Features : Overload/Short Circuit/Overvoltage/Overtemperature

Backup Power : Yes

Battery Type : Lead-acid/Lithium

Solar Charge Controller : MPPT

Maximum Output Power : 5000W

Grid Tie Function : No

Inverter Type : Hybrid

Communication Interface : RS485/Wi-Fi

Lcd Display : Yes

Contact Now

Product Parameter:

Inverter Data
MODEL	3500HHS-24	5500HHP-48
CAPACITY	3.5KVA/3.5KW	5.5KVA/5.5KW
Parallel Capability	NO	Yes,12pcs
INPUT
Nominal Voltage	230VAC
Acceptable Voltage Range	170-280VAC(For personal Computer);90-280VAC(For Home Appliances)
Frequency	50/60 Hz(Auto sensing)
OUTPUT
Nominal Voltage	220/230VAC±5%
Surge Power	7000VA	11000VA
Frequency	50/60 Hz
Waveform	Pure sine wave
Transfer Time	10ms(For personal Computer):20ms(For Home Appliances)
Peak Efficiency (PV to INV)	96%
Peak Efficiency (Battery to INV)	93%
Overload Protection	5s@>=150%load; 10s@110%~150%load
Crest Factor	3:1
Admissible Power Factor	0.6~1(inductive or capacitive)
BATTERY
Battery Voltage	24VDC	48VDC
Floating Charge Voltage	27VDC	54VDC
OverCharge Protection	33VDC	63VDC
Charging Method	CC/CV
SOLAR CHARGER & AC CHARGER
Solar Charger TYPE	MPPT
Max.PV Array Power	4000W	5500W
Max.PV Array Open Circuit Voltage	500VDC
PV Array MPPT Voltage Range	120VDC-450VDC
Max.Solar Input Current	15A	18A
Max.Solar Charge Current	100A	100A
Max.AC Charge Current	60A	60A
Max.Charge Current(PV+AC)	100A	100A
PHYSICAL
Dimensions,DWH(mm)	482290113
Package Dimensions,DWH(mm)	565380190
Net Weight(Kgs)	9	10
Communication Interface	USB/RS232/Dry-contact
ENVIRONMENT
Operating Temperature Range	(-10°C to 50℃)
Storage temperature	(-15°C to 60℃)
Humidity	5%to 95%Relative Humidity(Non-condensing)

24V 48V Off Grid Hybrid Solar Inverter RS485 / Wi-Fi Communication Interface

1) Pure sine wave solar inverter

2) Output power factor 1

3) High PV input voltage range

4)Built-in MPPT solar controller

5)Battery equalization function tooptimize battery performance andextend life-cycle

6)Inverter running without battery

7) Built-in anti-dusk kit for harshenvironment
